The TRIRON N series controllers are modular-designed products based on six MPPT solar controller models. With the advanced MPPT control algorithm and the adaptive three-stage charging mode based on a digital control circuit, TRIRON N series controllers obtain the maximum energy from solar modules and effectively prolong the lifecycle of batteries, significantly improve the system performance and support all-around electronic protection functions.
- 40A; System nominal voltage: 12V / 24V; Max. PV open circuit voltage: 100V
- MPPT tracking efficiency over 99.5%
- Maximum charge conversion efficiency of up to 98%
- Design of the master-slave interface module
- Support battery types: Lead-acid battery: AGM, GEL, Flooded, User; Lithium battery (additional accessories from EPEVER such as eBox-Wifi / Bluetooth, USB-RS485 cable are required for parameter setting of the lithium battery and USER)
